6
not allowed.
When the maximum length of the ue systems is exceeded, as shown in table [4], the diameter of
the single ue sets, including extension pipes and elbows, must be increased by one size.
Caution:
- The values shown in the resistance table [4] apply only to the delivered and advised ue systems
supplied by the manufacturer.
- Discharge material with a different resistivity can inuence the length of the total supply and
discharge route.
- The Ph-value of condensate is 3.4!
The roof and wall pass-throughs supplied by the manufacturer are identied by the following item
numbers:
Appliance type Roof pass-through C33 Wall pass-through C13
G+ 15/25/35/40
G+ 60/80/100
G+ 135/150/200
59 90 557
59 90 561
59 90 564
59 90 581
59 90 585
59 90 589
The extension pipes and bends of the gas ue exhaust system must satisfy the following
requirements:
Appliance type Minimum diameter
G+ 15/25/35/40
G+ 60/80/100
G+ 135/150/200
80 mm
100 mm
130 mm
