Cooling system, units with dryer
The cooling system of the version with dryer comprises oil cooler (Co), air receiver (AR) and fan
(FN).
The dryer (DR) has a separate cooling fan and an automatic condensate drain (see also section
Air dryer).
2.5 Regulating system
Detail view of unloader assembly (UA)
The main components of the regulating system are:
Instruction book
18 2920 7201 40
