Electric cubicle UL (YD)
Reference Designation
F1 Primary fuse, transformer of the control circuit
F2–3 Fuses
FM1 Motor overload relay
KA Auxiliary circuit relay
KD Delta contactor
KL Line contactor
KY Star contactor
T1 Transformer
X1 Terminal block of the control circuit
X2 Terminal block, voltage change of the motor (only on tri-voltage units)
Electrical diagram
2205 0315 00 Service diagram (DOL) for 10 and 15 hp
2205 0315 01 Service diagram (YD) for 20 hp
The complete electrical diagram can be found in the electric cubicle.
The complete electrical diagram can be found on the USB supplied with the machine.
Instruction book
22 2920 7201 40
