6. TECHNICAL SPECS
INPUT IMPEDANCE: 1.5 Mohm / 6 Vpp
OUTPUT IMPEDANCE: 100 ohm / 6 Vpp
DRY: ∞ ÷ 0 dB
OCT1: ∞ ÷ 0 dB
OCT2: ∞ ÷ 0 dB
POWER REQUIREMENTS  DC INPUT: +9/+12VDC or standard 9-volt battery
DIMENSIONS: 81.8 x 54.8 x 124.5 mm
6.7” x 5.7” x 2.4”
WEIGHT: 350 g
0.77 lbs
Mark your own preferred settings on the User Setting Chart below.
USER SETTING CHART MAKE UP YOUR OWN!
7. BLOCK DIAGRAM
In
dry
Out
oct1
oct2
oct2
oct1
