05
4.2 MICROMARK/MICROMARK 801 FUNCTIONS OVERVIEW (REAR PANEL)
SPEAKER ON/OFF (6)
Use this switch to turn o the amp’s speaker when using headphones or using only the extension cabinet.
LINE OUT (8)
This balanced XLR output may be used for recording or live situations. Use an XLR cable to connect your amp to a soundboard, snake
or soundcard.
GROUND LIFT (7)
When you detect a hum from your line out signal, switching the ground lift will more than likely eliminate it.
SPEAKER (9)
Using a standard 1/4” speaker cable, this jack can be used to connect to a Markbass “Tweeter Box” for increased high end response, or
to an 8 ohm extension cabinet to create a louder 60W rig!
