Markilux MX-1 compact - LED Spotlights in the Front Profile; LED Ambient Lighting; LED Line; Maintenance and Care

10
1 2 3
3
1 2 3
1. Loosen the hexagon nut (2) with a
SW 13 spanner. Subsequently, turn
the defective LED-Spot light (1) anti-
clockwise by 90° too bring the clamp
plate (3) in running direction of the
groove and remove.
2. Disconnect the plug (3) of the
defective spot light from the mains and
plug in the new spot light.
Item no. new LED-Spot 12 Volt with
plug: 714881
3. Place the new LED spotlight (1) into
the track, turn clockwise by 90° to
hook the clamp plate (3) in the groove.
Subsequently retighten the hexagon
nut (2).
For proper cleaning of the awning cover and the awning frame of your markilux awning, kindly pay close attention to the
cleaning instructions in chapter "Important notes".
The screen profile for LED ambient lighting (optional) in the front profile is made of acrylic glass (PMMA). Dirty cover
profiles should always be cleaned with water. Use mild soaps or detergents suitable for delicate fabrics in lukewarm water.
Abrasive cleaners, strong detergents, spray cleaner for glass, scouring cloths or brushes as well as solvents such as acetone,
carbon tetrachloride, paint thinner or alcohol mixtures with more than 5% alcohol content may be aggressive to the surface
and should never be used.
Repair and maintenance jobs such as the replacement of spare parts, a damaged outer flexible line or other electrical
components, must be carried out exclusively by the specialist dealer.
Repair and maintenance jobs such as the replacement of spare parts, a damaged outer flexible line or other electrical
components, must be carried out exclusively by the specialist dealer.
7.3 LED spotlights in the front profile
7.4 LED ambient lighting
7.5 LED line
8 Maintenance and care
