37
Sound functions
Sound-Nr.
Default Values
CV Steam CV Diesel CV Electric
Sound effect: Function f2 300 Running sounds 300 Running sounds 300 Running sounds 180 0 - 255
Sound effect: Function f3 301 1 301 1 301 1 180 0 - 255
Sound effect: Function f7 303 3 302 2 302 2 180 0 - 255
Sound effect: Function f10 309 9 309 9 309 9 180 0 - 255
Sound effect: Function f11 302 2 303 3 303 3 180 0 - 255
Sound effect: Function f12 304 4 304 4 304 4 180 0 - 255
Sound effect: Function f13 310 10 307 7 308 8 180 0 - 255
Sound effect: Function f14 314 14 314 14 314 14 180 0 - 255
Sound effect: Function f15 305 5 305 5 305 5 180 0 - 255
Total volume (CV63) and brake squeal (CV 146) see tables below.
Volume
mfx protocol: The total volume for the sound functions can be changed easily with the 60213/60214/60215 Central Station in the CV
menu “Sound”. The function mapping (assigning the function buttons) and the individual volume settings are done with the function
buttons. The sound number is required for the function mapping.
fx protocol: In the fx protocol only the total volume can be changed with CV 63. It is not possible to change the individual volumes.
However, settings done under mfx are preserved.
DCC protocol: To change the individual sound volume must be 31 CV changed to the value 16 and CV 32 to 0 before. The sound
number is required for the function mapping and for the assignment of the CVs to the sound.
