marklin 60975 - CV Table for fx (MM)

38
CV
Explanation Values Default Notes
1
Address 1 (main address) 1-255 (1 - 80)*
60975=78
60976=72
60977=24
Address is always active and is not subject
to CV 49..
2
Minimum speed (Vmin) 1-255 (1 - 80)*
4
Speed at the smallest speed level. Value
must be smaller than Vmax, CV 5.
3
Acceleration delay (AV) 1-255 (1 - 80)*
12
CV value multiplied by 0.25 gives the time
from complete stop to maximum speed.
4
Braking delay (BV) 1-255 (1 - 80)*
12
CV value multiplied by 0.25 gives the time
from Maximum speed to complete stop.
5
Maximum speed (Vmax)
1-255 (1 - 63)*
{x4}*
180
Speed at the highest speed level. Value must
be greater than CV 2.
7
Automatic Calibration
77
Enter Value 77. Value 77 is not stored
continuously.
8
Decoder reset (default or factory setting) 8 Value is not written.
17
Address 3 (2nd consecutive address) 1-255 (1 - 80)*
254
Address can be deactivated/activated
subject to CV 49.
18
Address 4 (3rd consecutive address) 1-255 (1 - 80)*
253
Address can be deactivated/activated
subject to CV 49.
27
Braking mode:
Bit 0 - 3 : always 0,
Bit 4 : DC voltage, polarity against the
direction of travel
Bit 5 : DC voltage, polarity with the direction
of travel
Bit 6 - 7 : always
0 - 48
0
16
32
0
48
Braking subject to direction:
- 16 normal DCC properties
- 32 inverse DCC properties
Braking not subject to direction:
- 48: fx/mfx properties
CV Table for fx (MM)
* () = 6021 Control Unit {} = the values entered are multiplied times “x” (factor).
