CV Table for DCC
CV
Explanation
Values
Default Notes
173
PoM
Storing different states:
Bit 0: Storing function states
Bit 1: Storing speed
Bit 2: After a reset starting up with/without ABV
Bit 3 - 7: always 0
0 / 1
0 / 2
0 / 4
7
0 = do not store, value = store
Individual values must be added.
174
PoM
Storing different states:
Bit 0: Storing direction of travel
Bit 1 - 7: always 0
0 / 1
1
0 = do not store
1 = store
176
PoM
Vmin Analog DC 0 - 255
50
Must be smaller than CV 177
177
PoM
Vmax Analog DC 0 - 255
170
Must be larger than CV 176
178
PoM
Vmin Analog AC 0 - 255
60
Must be smaller than CV 179
179
PoM
Vmax Analog AC 0 - 255
190
Must be larger than CV 178
CV 31 must first be set to the value 16 and CV 32 to the value 0 (see CV 31) to change the volumes (CV 300 - CV 328).
300
PoM
301
PoM
-
328
PoM
Sound output: Volume of running sounds*
Sound output: Volume for Sound 1*
up to
Sound output: Volume for Sound 16*
0 - 255
0 - 255
0 - 255
180
180
180
0 = no sound
PoM must be supported by the locomotive
controller / central controller.
* An extensive table for function mapping can be found on the Internet at:
www.maerklin.de/de/produkte/tools_downloads/technische_infos.html
