Lay the new circuit board on the motor, and carefully bend
the solder tabs back into place. Solder the motor with
both solder tabs to the new circuit board.
1
W
W = white
Guide the two white wires through the locomotive frame.
Stick the two cardan shafts into their sockets and reas-
semble the motor and shafts.
