3
Not suitable for children under 15 years.
The transformer must not be moved while the train is being
operated. After the transformer has been turned off, it must
never be carried by holding it by its power cord.
1. Read the following safety information before using a
Märklin transformer for the first time:
• Alltransformersmustbepluggedonlyintoanoutletwith
thehouseholdcurrentindicatedonthefaceplateofthe
transformer.
Example:Identicationplateforthe120volttransformer.
0
50
100 150
200
250
1
2
3 4
5
1–Speedcontroller
2–Powercord
3–Yellowterminalclip(“L”=accessorypower)
4–Brownterminalclip(“0”=groundreturn)
5–Redterminalclip(“B”=trackpower)
