Normal Use
• Thisdigitalinstallationdecoderisdesignedforinstallationin
Märklin and Trix C Track turnouts with a turnout mechanism
(exception: Märklin three-way turnout).
• Thisdigitalinstallationdecodermayonlybeconnectedto
Märklin or Trix switched mode power packs for external
power supply.
• Thisdecodermayonlybeusedindryareasindoors.
Contents as Delivered
1 digital installation decoder
1 cable – yellow, red, and brown (for Märklin C Track)
1 cable – blue, red, and white (for Trix C Track)
Installation instructions
Warranty card
Additional tools required for installation: tweezers and solder-
ing station for a maximum soldering temperature of 30 watts /
300˚ Celsius / 572˚ Fahrenheit with a fi ne point, Electronic solder
(0.5-1 mm dia.), desoldering braid or desoldering pump.
Safety Notes
• IMPORTANT! This product has sharp edges and points related
to its function.
• Dowiringandassemblyworkonlyinavoltage-freework
environment. Otherwise you may experience electrical current
dangerous to the body leading to injury.
• Operate this decoder only with the permissible voltage
(see technical information).
When using a solder station there is the danger of burning
your skin.
Important Information
• Important: When installing the digital installation decoder,
try to avoid touching components on the upper side of the
decoder. Static charge can affect the function of the decoder.
• Theoperatinginstructionsareacomponentpartofthe
product and must therefore be kept with the product,
particularly when it is given to another party.
• ForrepairspleaseseeyourauthorizedMärklinspecialty
dealer.
• http://www.maerklin.com/en/imprint.html
Technical Data
• Loadatlanternoutput ≤ 100 milliamps
• Loadatturnoutoutput max.2amps
• Voltageforthedigitalpowercircuit max.20voltseff.
• Externalvoltage max.20voltsDC
• Electricalstrength max.40volts
Functions
• Capableofmulti-protocols:fx(MM)andDCC
• ModeofoperationsetwithDIPswitches
• AddressescanbesetwithDIPswitches:
1-256 fx (MM) (Control Unit 6021/Mobile Station 60651/652)
1-320 fx (MM) (Central Station 6021x/Mobile Station 60653)
1-511 (DCC)
• ProgrammableaddressesusingCVs
1-2,044 DCC
• ChangestocharacteristicscanbedonewithCVs
• Digitalsignal:transferindependentofthepowersupply
• Powersupplydoneusingthedigitalpowercircuit
• Alternativepowersupply
• Solderpadsforconnectionsforturnoutlanterns
• Turnoutlanternscanbeturnedonoroff
