Not suitable for children under 15 years.
The transformer must not be moved while the train is being
operated. After the transformer has been turned off, it must
never be carried by holding it by its power cord.
1. Safety Information for the Operation of
Märklin Transformers
Read the following safety information before using a
Märklin transformer for the first time:
• Alltransformersmustbepluggedonlyintoanoutletwith
thehouseholdcurrentindicatedonthefaceplateofthe
transformer.
Example:Identicationplateforthe120volttransformer.
1–Speedcontroller
2–Powercord
3 –
Yellowterminalclip(powerconductorforturnouts,signals,etc.)
4–Grayterminalclip(groundconductorforturnouts,signals,etc.)
5–Brownterminalclip(groundconductorfortrackpower)
6–Redterminalclip(powerconductorfortrackpower)
L I S T E D
1 D 8 1
C
Toy Trans former
INP UT
OUT P UT
C AUTION
E L E C TR IC -TOY
120V AC 60Hz
0-10V DC 8VA
10V A C 8VA
Made in G ermany
P /N 36-010 2S T E G E R
67271

marklin 81705 Specifications

General

Brand	marklin
Model	81705
Category	Transformer
Language	English
