Marlo Incorporated CMP Series - Page 14

13
16
17
18
19
25a, 25b
24
23
22
20
30
26
35
33
32
34
29
27
28
31
21
�
�
�
Injector Cap, Injector Screen, Injector, Plug ,
O-Ring, Refill and Refill Port Plug,
&Drain Line - 3/4”
Proper flow washer orientation
directs water flow towards the
washer face with rounded edge.
Flow washer indentification
numbers must be visible after
installation.

Part of Kit, O-ring (Item #51, pg. 20)
8-198 R1
“CMP & C” Series Automatic Water Conditioners
