Marlo Incorporated CMP Series - Injector Cap, Injector Screen, Injector, Plug and O-Ring; Drain Line

14
Drawing No. Order No. Description Quantity
21 V3195-01 Refill Port Plug Assembly This part is required for backwash only systems
22 H4615 Elbow Locking Clip 1
23 JCP-P-6 Polytube insert 3/8 1
24 JCPG-6PBLK Nut 3/8 1
25a H4613 Elbow Cap 3/8 (use w/ 3/8” tubing) 1
25b H4650 Elbow 1/2” with nut and insert (use w/ 1/2” tubing) Option
26 V3163 O-Ring 019 ( Use Valve O-ring Kit ) 1
27 V3165-01 RFC Retainer Assembly* 1
28 RFC Brine Refill Flow Washer 1
*Assembly includes RFC.
Refill and Refill Port Plug
Drawing No. Order No. Description Quantity
29 H4615 Elbow Locking Clip 1
30 PKP10T58-BULK Polytube insert 5/8 Option
31 V3192 Nut 3/4 Drain Elbow Option
32 V3158-01 Drain Elbow 3/4 Male Assembly 1
33 V3163 O-Ring 019 (Use Valve O-ring Kit) 1
34 V3159-01 Drain Flow Washer Retainer Assembly 1
V3162-007 Drain Flow Washer 0.7 gpm for 3/4
V3162-010 Drain Flow Washer 1.0 gpm for 3/4
V3162-013 Drain Flow Washer 1.3 gpm for 3/4
V3162-017 Drain Flow Washer 1.7 gpm for 3/4
V3162-022 Drain Flow Washer 2.2 gpm for 3/4
V3162-027 Drain Flow Washer 2.7 gpm for 3/4
V3162-032 Drain Flow Washer 3.2 gpm for 3/4
V3162-042 Drain Flow Washer 4.2 gpm for 3/4
V3162-053 Drain Flow Washer 5.3 gpm for 3/4
35
One
DLFC
must be
used if 3/4
fitting is
used
Drain Line - 3/4”
Item No. Part No. Description Quantity
16 V3176 Injector Cap 1
17 V3152 O-Ring 135 (Use Valve O-ring Kit) 1
18 V3177 Injector Screen 1
19 V3010-1Z Injector Assembly Z Plug See note 1
V3010-1A Injector Assembly A Black
V3010-1B Injector Assembly B Brown
V3010-1C Injector Assembly C Violet
V3010-1D Injector Assembly D Red
20 V3010-1E Injector Assembly E White
V3010-1F Injector Assembly F Blue
V3010-1G Injector Assembly G Yellow
V3010-1H Injector Assembly H Green
V3010-1I Injector Assembly I Orange
V3010-1J Injector Assembly J Light Blue
V3010-1K Injector Assembly K Light Green
*The injector plug and the injector each contain one 011 (lower) and 013 (upper) o-ring.
Note: For downflow brine, injector is located in the down hole and injector plug in the up hole.
For a filter that only backwashes injector plugs are located in both holes.
1
Injector Cap, Injector Screen, Injector, Plug and O-Ring



8-198 R1
“CMP & C” Series Automatic Water Conditioners
