Marlo Incorporated CMP Series - Drive Cap Assembly, Downflow Piston, Upflow Piston, Regenerant Piston and Spacer Stack Assembly; Front Cover and Drive Assembly

12
Front Cover and Drive Assembly
Item No. Part No. Description Quantity
7 V3175CC-01 Front Cover ASSY 1
8 V3107-01 Motor 1
9 V3106-01 Drive Bracket & Spring Clip 1
10 V3108 PC Board 1
11 V3110 Drive Gear 12 x 36 3
12 V3109 Drive Gear Cover 1
13 V3193-01 Service Tool 1
14 V3186 Transformer 110V - 12V 1
Drive Cap Assembly, Downflow Piston, Upflow Piston,
Regenerant Piston and Spacer Stack Assembly
Item No. Part No. Description Quantity
1 V3005 *Spacer Stack Assembly w/o o-rings 1
2 V3004 Drive Cap Assembly 1
3 V3135 O-Ring 228 (use Valve O-ring Kit) 1
4 V3011 Piston Downflow Assembly 1
5 V3174 Regenerant Piston 1
6 V3180 O-Ring 337 (use Valve O-ring Kit) 1
15 V3105 O-Ring 215
(use Valve O-ring Kit)
1






Item #5 not used with Backwash Only filter applications.

Item #4 identified with “DN” code.
8-198 R1

See page 20 for Valve O-ring Kit.
“CMP & C” Series Automatic Water Conditioners
