Order No: V3007 (Standard)
Description: Fitting 1” PVC Male NPT Elbow Assembly
Drawing No. Order No. Description Quantity
1 V3151 Nut 1” Quick Connect 2
2 V3150 Split Ring 2
3 V3105 O-Ring 215 2
4 V3149 Fitting 1”PVCMaleNPT Elbow 2
Order No: V3007-01 (Optional)
Description: Fitting 3/4” & 1” PVC Solvent 90
0
Asy
Drawing No. Order No. Description Quantity
1 V3151 Nut 1” Quick Connect 2
2 V3150 Split Ring 2
3 V3105 O-Ring 215 2
4 V3189 Fitting 3/4&1 PVC Solvent 90 2
Order No: V3007-03 (Optional)
Description: Fitting 3/4” Brass Sweat Assembly
Drawing No. Order No. Description Quantity
1 V3151 Nut 1” Quick Connect 2
2 V3150 Split Ring 2
3 V3105 O-Ring 215 2
4 V3188-01 Fitting 3/4” Brass Sweat 2
Order No: V3007-02 (Optimal)
Description: Fitting 1” Brass Sweat Assembly
Drawing No. Order No. Description Quantity
1 V3151 Nut 1” Quick Connect 2
2 V3150 Split Ring 2
3 V3105 O-Ring 215 2
4 V3188 Fitting 1” Brass Sweat 2
