MARLO MR-450-2 - Table of Contents; System Information; Dimension Width

MR 150M–1050M SINGLE – MXIII CONTROLLER
SYSTEM INFORMATION
2
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
A A B B C C
D D
DATE
FRAC.
DRN.
APP'D.

DEC.

DRAWING NO.
SCALE FILE ID.
SHEET
REV.
OF
MR SINGLE WATER SOFTENER SYSTEM NXT
GENERAL ARRANGEMENT
MR SINGLE NXT
1 1
Anthony
5/25/2011
REVISIONS
NO. BY REMARKS
INCORPORATED
DATE
BRINE TANK
BT DIAMETER
MINERAL TANK
MT DIAMETER
INLET=_________ OUTLET=_______
PIPE SIZES
INJECTOR=_______
DRAIN=__________
H=_______
MT=_______
DIMENSION TABLE
BT=_______
MR-______________
W=_______ L=_______
H
L
W
INLET 30-100 PSIG
OUTLET
BY-PASS VALVE
(NORMALLY CLOSED)
INLET ISOLATION
VALVE
OUTLET ISOLATION
VALVE
BRINE INJECTOR
RAW WATER INLET
30-100 PSIG
BACKWASH FLOW
CONTROLLER
DRAIN
STRAINER
OPTIONAL WATER
METER
NOTES: ALL PIPING, FITTINGS, ETC SHOWN WITH DASHED LINES
ARE PROVIDED BY OTHERS. GENERAL PLUMBING CONNECTIONS ARE SHOWN FOR
CLARITY ONLY. MINERAL TANKS SMALLER THAN 36" DIAMETER HAVE
HANDHOLES.
OVER FLOW
TO DRAIN
CONTROLLER
