© MARMITEK
6 Technical specifications
Connections
HDMI input 4 x HDMI (19-pin female)
HDMI output 1 x HDMI (19-pin female)
HDMI cable length max. 15 metres
Video
Supported resolutions 4K
(4096x2160)@24/30/50/60Hz,
480i~1080p@50/60Hz,1080p
@120Hz and
3D@1080p/60Hz.
Supported PC resolutions max. QSXGA
(2560x2048@60Hz).
HDMI standards HDMI 2.0b, HDR, CEC, EDID,
DVI, all 3D formats and Deep
Color 36-bit.
HDCP standards HDCP 2.2 and HDCP 1.4
Colour formats RGB and YCbCr 4:4:4, 4:2:0
or 4:2:2.
Colour depth max. 36-bit.
Throughput speed max.18 Gbit/s.
Clock frequency max. 600 MHz.
Audio
HDMI audio formats DTS-HD Master Audio, Dolby
TrueHD,
Dolby Atmos, DTS:X, Dolby
Digital/ AC3,
DTS 5.1 and PCM stereo.
Housing
Dimensions (H x W x D) 120 x 78 x 17 mm
Weight 210 g
Environment
Ambient temperature +0 to +40° C
