Marmitek Connect TS41 User Manual

© MARMITEK
6
6.2 Left
1. Optical In: Connect your
audio sources to these inputs
with an optical (Toslink)
digital audio cable (not
supplied).
6.3 Right
1. Power: Press this button to
switch the Connect TS41 on
or to standby mode.
2. Input: Use this button to
select which audio input is
switched to the audio output.
3. Optical Out: Connect your
audio amplifier or powered speakers to this output using an
optical (Toslink) digital audio cable (not supplied).
4. IR: IR sensor for receiving the supplied remote control's
infra-red signals. For correct operation, make sure it is placed
in your remote control's line of sight.
6.4 Back
1. DC 5V: Connect the power
adapter (included) and plug it
into the mains.
4321
O ptic a l In
1
Power Input Optical
Out
IR
1 2 3 4
DC 5V
1

Marmitek Connect TS41 Specifications

General

Brand	Marmitek
Model	Connect TS41
Category	Switch
Language	English
