Mars PS-121B User Manual

Installation, Operation & Maintenance Manual - PS-121B / PSH-141A
7
7
Installation
Step Three: Preparing the Adjustable Window Slider
1. Depending on the size of your window, adjust the size
of the window slider.
2. If the length of the window requires two window sliders,
use the bolt to fasten the window sliders once they are
adjusted to the proper length.
Cut the adhesive foam seal
A and B strips to the proper
lengths, and attach them to
the window sash and frame
as shown.
Insert the window slider
assembly into the window
opening.
Insert the window slider
adaptor into the hole of
the window slider.
Cut the non-adhesive foam
seal C strip to match the
width of the window. Insert
the seal between the glass
and the window frame to
prevent air and insects from
getting into the room.
Note:
Once the Exhaust Hose assembly and Adjustable Window Slider are prepared,
choose from one of the following two installation methods.
Type 1: Hung Window Installation
Window slider A Window slider B
Bolt
Foam seal B
(Adhesive type-shorter)
Foam seal A
(Adhesive type)
Window slider A
Window slider B
(if required)
Foam seal C
(Non-adhesive type)
If desired, install the
security bracket with two
screws as shown.
2 Screws
Security Bracket
