Installation, Operation & Maintenance Manual - PS-121B / PSH-141A
8
Installation
8
Cut the adhesive foam seal
A and B strips to the proper
lengths, and attach them to
the window sash and frame
as shown.
If desired, install the
security bracket with two
screws as shown.
Insert the window slider
adaptor into the hole of
the window slider.
Insert the window slider
assembly into the window
opening.
Cut the non-adhesive foam
seal C strip to match the
window height. Insert the
foam seal between the
glass and the window frame
to prevent air and insects
from getting into the room.
Type 2: Sliding Window Installation
Note:
To ensure proper function, DO NOT over-extend or bend the hose. Make sure
that there is no obstacle around the air outlet of the exhaust hose (in the range of
500mm) in order for the exhaust system to work properly. All illustrations in this
manual are for explanation purposes only. Your air conditioner may be slightly
different. The actual shape shall prevail.
Foam seal B
(Adhesive type-shorter)
Foam seal A
(Adhesive type)
Window slider A
Window slider B
(if required)
Foam seal C
(Non-adhesive type)
2 Screws
Security
Bracket
