15
42900 Rev. 09-30-2008
Item Number Part Number Description
1 RP40401 Water Bottle with Duckbill
2 RP33460 Duckbill Valve (Qty 5)
3 RP40404 Rear Water Bottle Bracket with Screw
4 RP40403 Front Water Bottle Bracket with Screw
5 RP40407 Brush
6 RP40405 Brush Tank
7 RP40517 Tape Weight with Screw
8 RP40325 Cutter Guard with Screws
9 RP40310 Top Cover
10 RP40311 Top Cover Hinge with Screw (Qty 2)
11 RP40505 Pressure Plate
