Maintenance
The Marsh TD2100 requires very little maintenance, but it is important to regularly clean the
brush, brush tank, cutter mechanism, and remove debris from the tape path.
CAUTION: Before beginning maintenance or adjustments be sure the tape machine is
turned OFF and unplugged.
Cleaning Water Feed System
1. Turn the power switch to the OFF position and unplug the power cord.
2. Clean the brush by soaking it in warm soapy water and then rinse.
3. Clean the brush tank by rinsing it with warm water.
4. Rinse out the water bottle and duckbill valve with warm water.
Figure 9 – Cleaning the Cutter Assembly, Cleaning the Tape Path
Cutter
Assembly
Tape Channel
Pressure Plate
Top Cover
Cutter Guard
Cleaning Gaps
Weighted Brush
Tank Cover
Water Tank
Holder
To Next Page
