Troubleshooting
This section describes potential problems you may encounter while working with your TD2100
tape machine and outlines possible causes and solutions for these problems. To avoid problem
situations, be sure to follow the procedures in the setup and maintenance sections. Before
performing any repair procedures be sure that the power switch is in the OFF position and
the Tape Machine is disconnected from the power source. For further assistance please
contact your Marsh distributor or MSSC, LLC technical support at;
Telephone: (573)-437-7030
Fax: (573)-437-4030
Email: quality.ovl@msscllc.com
The machine will not dispense tape.
Possible Cause: Solution:
1. Is the machine
plugged in?
Plug the machine in.
2. Is the power switch
in the on position?
Turn the power switch on.
3. Is the machine in
program mode, is
the display
flashing?
Press program key to turn off program mode or finish program
cycle OR cycle the power off and then back on
Tape is jamming, tearing, or won’t feed.
Possible Cause: Solution:
1. Is there debris in the
tape path?
Clean the tape path, refer to the maintenance section.
2. Are the tape guides
too tight?
Adjust the tape guides with the tape guide turnbuckle, refer to
the loading tape section.
3. Is the tape routed
correctly?
Route the tape according to Figure 3 (p. 7).
4. Is the pressure plate
in place?
Verify that the pressure plate is in place. The pressure plate
must be loaded so it touches the pinch roller shaft and the
arrow on the pressure plate points toward the front of the
machine.
5. Is there to much
weight on the
brush?
Adjust the amount of weight on the brush, refer to the setup
section.
6. Is the cutter cutting
the tape?
Clean the cutter assembly, refer to the maintenance section, if
problem persists contact your Marsh distributor or MSSC, LLC.
