ENGLISH
4
1. Mains Input
Plug your mains lead in here.
2. Footswitch Jack
Jack socket for connection of the optional
footswitch (model PEDL-10029) for switching the
Reverb and Chorus functions on and off.
3. Line Out Jack
Jack socket for connection to home recording or
other external equipment with jack inputs.
4. DI Out
XLR type output for connection to PA or similar
external equipment.
Note: Both the Line Out and DI out carry exactly
the same signal at different levels and both are
placed before the Master Volume so changing the
overall level of the amplifier will not affect the
signal from the DI or Line Output.
5. Effects Send Jack
Jack socket to connect to the input of an external
effects processor.
6. Effects Return Jack
Jack socket to connect to the output of an external
effects processor.
AS50R Rear Panel Features
