CV503/CV506/CV344/CV346 Manual
www.marshall-usa.com7 8
5. AE CONTROL
• AUTO: Adjusts the exposure level automatically. Detailed fine tuning options are available
under this menu.
• SHUT FIX: Provides more detailed shutter speed options. All other controls are tuned for the
selected shutter speed.
• AGC FIX: Provides more detailed gain option. All other controls are tuned for the selected gain
value.
• MANUAL: Adjusts the exposure level manually
1. SHUTTER: Speed can be set at auto or manual. (1/30~1/10,000)
2. IRIS SPEED: Electronic Iris speed can be controlled, for DC Iris lens only. (0~5)
3. AGC: Electronic Iris speed can be controlled, for DC Iris lens only. (0~5)
4. AGC MAX: Used to set maximum gain value to control the video noise caused by Auto
Gain Control. (Off, Low, Middle, High, DMIN, DMID, DMAX)
5. SENS UP: Controls the digital slow shutter to allow extra light into the camera and adjust
the picture quality. (Off, x2~x10)
6. AE BRIGHT: Select this to adjust auto exposure brightness levels. (0~10)
7. LENS MODE: Lens setting will be optimized for selected environment, for DC Iris lens only.
8. FLK CONTROL: Provides a proper image sensor frequency to match the power frequency
in order to minimize video flicker.
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
AE MODE
SHUTTER
IRIS
AGC
AGCMAX
SENS UP
AE BRIGHT
FLK CONTROL
LENS MODE
RETURN
>
>
>
>
>
>
>
>
AUTO
13
OFF
6
OFF
MENU AE CONTROL
Select AE CONTROL using the UP or DOWN button. You can select one sub-mode using the UP or
DOWN buttons.
MODE: Set camera to either color mode or B&W mode. (Day, Night)
DAY: When set to DAY mode, camera stays in color and IR cut filter is engaged.
NIGHT: When set to NIGHT mode, camera stays in B&W and IR cut filter is removed.
• NIGHT COLOR: When on, camera stays on color mode. Night (B&W) can be selected from
this mode. (On, Off)
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
MODE
NIGHT COLOR
RETURN
>
>
>
>
>
>
>
>
DAY (COLOR)
MENU DAY/NIGHT
6. DAY / NIGHT
Select DAY / NIGHT using the UP or DOWN button. You can select one sub-mode from AUTO,
COLOR, and NIGHT using the UP or DOWN buttons.
