• DZOOM: Digitally zoom the video by the desired ratio.
• DEFOG: This feature will help increase visibility in extreme weather conditions, such as fog,
rain or in a very strong luminous intensity.
• DIS: This feature enables digital image stabilization
• BACKLIGHT: Adjust backlight compensation by choosing either BLC HLM from this menu.
• BINNING: Enable or disable pixel binning.
• DEFECT PIXEL: Advanced defective pixel correction menu.
• DISP FUNCTION: Display effect such as freeze mirror, rotation, and style can be applied from
this menu.
• WDR: This feature enables user to view both object and background more clearly when
background is too bright.
• FLICKER DETECT: Adjust the image sensor frequency to match the power frequency.
• PRIVACY: Mask an area you want to hide on the screen by applying the privacy zones.
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
DZOOM
DEFOG
DIS
BACKLIGHT
BINNING
DEFECT PIXEL
DISP FUNCTION
WDR
FLICKER DETECT
PRIVACY
RETURN
>
>
>
>
>
>
>
>
OFF
OFF
OFF
OFF
OFF
ON
>
OFF
OFF
>
MENU SPECIAL
9. SPECIAL
Select SPECIAL using the UP or DOWN button.
You can select DEFOG, MOTION DETECT, BACKLIGHT, DEFECT PIXEL, and FLICKER DETECT using
the UP or DOWN buttons.
• CAM TITLE: Camera title can be turned ON or OFF.
• COMMUNICATION: VISCA communication can be adjusted.
1. CAM ID: Camera ID can be setup. (0~7)
2. ID DISPLAY: Camera ID display can be displayed.
3. BAUDRATE : Camera baudrate can be set.
(2400, 4800, 9600, 19200, 38400)
• SYSTEM INFO: Camera information can be found under this menu.
• OUTPUT FORMAT: Camera resolution and frame rate can be set.
(1080 by default)
Select the FRAME RATE using the LEFT or RIGHT buttons.
Available Frame Rates are:
1920 x 1080p 60, 59.94, 50, 30, 29.97, 25, 24, 23
1920 x 1080i 60, 59.94, 50
1280 x 720p 60, 59.94, 50
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
CAM TITLE
COMMUNICATION
SYSTEM INFO
OUTPUT FORMAT
RETURN
>
>
>
>
>
>
>
>
OFF
>
>
1080p 59.94
>
MENU SETUP
10. SETUP
CAMERA setup can be adjusted from this menu.
You can select CAMERA ID, Communication, System Info, and Output Format using the UP or DOWN
buttons.
