Marshall Amplification CV620-IP Command Set

CV620-IP / CV620-NDI RS-232 Command Set
www.marshall-usa.com7 8
14. AE_Gain Table
Gain
Index(pq) Value
0x0A +20 dB
0x09 +18 dB
0x08 +16 dB
0x07 +14 dB
0x06 +12 dB
0x05 +10 dB
0x04 +8 dB
0x03 +6 dB
0x02 +4 dB
0x01 +2 dB
0x00 0 dB
15. AE_Gain Limit Table
Gain
Index(p) Value
0x0A +20 dB
0x09 +18 dB
0x08 +16 dB
0x07 +14 dB
0x06 +12 dB
0x05 +10 dB
0x04 +8 dB
16. AE_Exposure Comp. Table
Exposure Comp.
Index(p) Value(Level)
0x0B 5
0x0A 4
0x09 3
0x08 2
0x07 1
0x06 0
0x05 -1
0x04 -2
0x03 -3
0x02 -4
0x01 -5
0x00 -6
17. Camera Command List
Command Set Command Command Packet Comments
AddressSet Broadcast 88 30 01 FF Address setting
IF_Clear Broadcast 88 01 00 01 FF I/F Clear
CommandCancel – 8x 2p FF p: Socket No. (=1 or 2)
CAM_Power
On 8x 01 04 00 02 FF
Power ON/OFF
Off (Standby) 8x 01 04 00 03 FF
CAM_AutoPowerOff Direct
8x 01 04 40 0p 0q
0r 0s FF
Auto Power Off, pqrs: 0000 To FFFF
pqrs: Power Off Timer 0000 (Timer
Off) to FFFF (65535min)
Initial value: 0000
The power automatically turns off if
the camera does not
receive any VISCA commands or any
signals from the
Remote Commander for the duration
you set in the timer.
CAM_Zoom
Stop 8x 01 04 07 00 FF
Tele (Standard) 8x 01 04 07 02 FF
Wide (Standard) 8x 01 04 07 03 FF
Tele Step 8x 01 04 07 04 FF
Wide Step 8x 01 04 07 05 FF
Tele (Variable) 8x 01 04 07 2p FF
p=0 (Low) to 7 (High)
Wide (Variable) 8x 01 04 07 3p FF
Direct
8x 01 04 47 0p 0q
0r 0s FF
pqrs: Zoom Position(0x0000~0x4000)
, Optical Zoom Tele max position:
0x4000
Direct(Speed
Variable)
8x 01 04 47 0p 0q
0r 0s 0t FF
pqrs: Zoom Position(0x0000~0x4000)
, Optical Zoom Tele max position:
0x4000, t:0~7(0 :Low, 7:High)
