Marshall Amplification CV620-IP Command Set

CV620-IP / CV620-NDI RS-232 Command Set
www.marshall-usa.com9 10
Command Set Command Command Packet Comments
CAM_Focus
Stop 8x 01 04 08 00 FF
p=0 (Low) to 7 (High)
(* Enabled during Manual Focus
Mode)
Far (Standard) 8x 01 04 08 02 FF
Near (Standard) 8x 01 04 08 03 FF
Far Step 8x 01 04 08 04 FF
Near Step 8x 01 04 08 05 FF
Far (Variable) 8x 01 04 08 2p FF
Near (Variable) 8x 01 04 08 3p FF
Direct
8x 01 04 48 0p 0q
0r 0s FF
pqrs: Focus Position , pqrs
parameters are in the General
Zoom Foucs Table 0x00 ~ 0x3C3
(* Enabled during Manual Focus Mode)
Auto Focus 8x 01 04 38 02 FF
AF ON/OFFManual Focus 8x 01 04 38 03 FF
Auto/Manual 8x 01 04 38 10 FF
One Push
Trigger
8x 01 04 18 01 FF
One Push AF Trigger(* Enabled during
Manual Focus Mode)
CAM_ZoomFocus Direct
8x 01 04 47 0p 0q
0r 0s 0t 0u 0v 0w
FF
pqrs: Zoom Position(0x0000~0x4000)
tuvw: Focus Position(0x00 ~ 0x3C3)
(* Enabled during Manual Focus
Mode)
Resolution Settting —
8x 01 06 35 00 0p
FF
p:
0x00:1080p-60
0x01:1080p-59.94
0x02:1080p-50
0x03:1080p-30
0x04:1080p-29.97
0x05:1080p-25
0x06:1080i-60
0x07:1080i-59.94
0x08:1080i-50
0x09:720p-60
0x0A:720p-59.94
0x0B:720p-50
Command Set Command Command Packet Comments
CAM_WB
Auto 8x 01 04 35 00 FF Normal Auto
Indoor 8x 01 04 35 01 FF Indoor mode
Outdoor 8x 01 04 35 02 FF Outdoor mode
One Push WB 8x 01 04 35 03 FF One Push WB mode
ATW 8x 01 04 35 04 FF Auto Tracing White Balance
Manual 8x 01 04 35 05 FF Manual mode
Sodium Lamp 8x 01 04 35 06 FF Sodium lamp source fixed mode
3000K 8x 01 04 35 07 FF Color temperture fixed at 3000K mode
4300K 8x 01 04 35 08 FF Color temperture fixed at 4300K mode
5000K 8x 01 04 35 09 FF Color temperture fixed at 5000K mode
6500K 8x 01 04 35 0A FF Color temperture fixed at 6500K mode
8000K 8x 01 04 35 0B FF Color temperture fixed at 8000K mode
WideAuto 8x 01 04 35 0C FF Wide Auto mode
One Push
Trigger
8x 01 04 10 05 FF
One Push WB Trigger(* Enabled during
One Push WB Mode)
CAM_WB_RGAIN
Reset 8x 01 04 03 00 FF
Manual R gain Setting
(* Enabled during WB Manual mode )
pq = 0x00 To 0x80
Up 8x 01 04 03 02 FF
Down 8x 01 04 03 03 FF
Direct
8x 01 04 43 00 00
0p 0q FF
CAM_WB_BGAIN
Reset 8x 01 04 04 00 FF
Manual B gain Setting
(* Enabled during WB Manual mode )
pq = 0x00 To 0x80
Up 8x 01 04 04 02 FF
Down 8x 01 04 04 03 FF
Direct
8x 01 04 44 00 00
0p 0q FF
CAM_AE
Full Auto 8x 01 04 39 00 FF Automatic Exposure mode
Manual 8x 01 04 39 03 FF Manual Control mode
Shutter Priority 8x 01 04 39 0A FF
Shutter Priority Automatic Exposure
mode
Iris Priority 8x 01 04 39 0B FF Iris Priority Automatic Exposure mode
White Board 8x 01 04 39 5F FF White Board Mode
Smooth Auto 8x 01 04 39 60 FF Smooth Auto
CAM_Shutter
Reset 8x 01 04 0A 00 FF
Shutter Setting
(* Enabled during AE Shutter Priority/
Manaual Mode)
pq: Shutter Position , pq: 00 To 15
Up 8x 01 04 0A 02 FF
Down 8x 01 04 0A 03 FF
Direct
8x 01 04 4A 00 00
0p 0q FF
CAM_Iris
Reset 8x 01 04 0B 00 FF
Iris Setting
(* Enabled during Iris Priority/Manaual
Mode)
Up 8x 01 04 0B 02 FF
Down 8x 01 04 0B 03 FF
Direct
8x 01 04 4B 00 00
0p 0q FF
pq: Iris Position , pq: 00 To0E
Iris Limit 8x 01 04 2B 0p FF
p: Iris F number , p: 0 To 7 (* Disabled
during AE Manual Mode and IrisPri
Mode)
