CV630-IP RS-232 Command Set
www.marshall-usa.com7 8
13. Camera RS232 Command List
Command Set Command Command Packet Comments
AddressSet Broadcast 88 30 01 FF Address setting
IF_Clear Broadcast 88 01 00 01 FF I/F Clear
CommandCancel – 8x 2p FF p: Socket No. (=1 or 2)
CAM_Power
On 8x 01 04 00 02 FF
Power ON/OFF
Off (Standby) 8x 01 04 00 03 FF
CAM_Zoom
Stop 8x 01 04 07 00 FF
Tele (Standard) 8x 01 04 07 02 FF
Wide (Standard) 8x 01 04 07 03 FF
Tele Step 8x 01 04 07 04 FF
Wide Step 8x 01 04 07 05 FF
Tele (Variable) 8x 01 04 07 2p FF
p=0 (Low) to 7 (High)
Wide (Variable) 8x 01 04 07 3p FF
Direct 8x 01 04 47 0p 0q 0r 0s FF
pqrs: Zoom Position(0x0000~0x4000) , Optical Zoom
Tele max position: 0x4000
Direct(Speed
Variable)
8x 01 04 47 0p 0q 0r 0s 0t FF
pqrs: Zoom Position(0x0000~0x4000) , Optical Zoom
Tele max position: 0x4000, t:0~7(0 :Low, 7:High)
Zoom Memory
Mode
8x 01 04 47 00 02 FF
Zoom Memory Mode ON/OFF
8x 01 04 47 00 03 FF
CAM_Focus
Stop 8x 01 04 08 00 FF
Enabled during Manual Focus Mode
Far (Standard) 8x 01 04 08 02 FF
Near (Standard) 8x 01 04 08 03 FF
Far Step 8x 01 04 08 04 FF
Near Step 8x 01 04 08 05 FF
Far (Variable) 8x 01 04 08 2p FF
p=0 (Low) to 7 (High)
(* Enabled during Manual Focus Mode)
Near (Variable) 8x 01 04 08 3p FF
Direct 8x 01 04 48 0p 0q 0r 0s FF
pqrs: Focus Position , pqrs parameters are in the
General Zoom Foucs Table 0x00 ~ 0x47A
(* Enabled during Manual Focus Mode)
Auto Focus 8x 01 04 38 02 FF
AF ON/OFF
Manual Focus 8x 01 04 38 03 FF
Auto/Manual 8x 01 04 38 10 FF
One Push Trigger 8x 01 04 18 01 FF
One Push AF Trigger(* Enabled during Manual Focus
Mode)
CAM_Curve
Curve tracking 8x 01 04 38 03 02 FF
Curve tracking ON/OFF
Zoom tracking 8x 01 04 38 03 03 FF
AF Sensitivity
High 8x 01 04 58 01 FF
High / Middle / LowMiddle 8x 01 04 58 02 FF
Low 8x 01 04 58 03 FF
Command Set Command Command Packet Comments
AF Frame
Auto 8x 01 04 5C 01 FF
Auto / Full Frame / Center
Full Frame 8x 01 04 5C 02 FF
Center 8x 01 04 5C 03 FF
Auto/Full Frame/
Center
8x 01 04 5C 10 FF
CAM_ZoomFocus Direct
8x 01 04 47 0p 0q 0r 0s 0t 0u
0v 0w 0x FF
pqrs: Zoom Position(0x0000~0x4000) tuvw: Focus
Position(0x0000 ~ 0x047A)
x:Speed(0~7)
(* Enabled during Manual Focus Mode)
CAM_Initialize Lens 8x 01 04 19 01 FF Lens Initialization Start
Resolution Settting Select Resolution 8x 01 06 35 0p 0q FF
pq:
0x05:QFHD 4K(3840 x 2160) - 29.97p
0x06:QFHD 4K(3840 x 2160) - 25p
0x08:FHD 1080P(1920 x 1080) - 59.94p
0x09:FHD 1080P(1920 x 1080) - 50p
0x0B:FHD 1080P(1920 x 1080) - 29.97p
0x0C:FHD 1080P(1920 x 1080) - 25p
0x0E:HD 720P(1280 x 720) - 59.94p
0x0F:HD 720P(1280 x 720) - 50p
0x11:HD 720P(1280 x 720) - 29.97p
0x12:HD 720P(1280 x 720) - 25p
HDMI Output Range
16~235 8x 01 06 37 01 FF
HDMI Output Range : 16~235 / 1~254
1~254 8x 01 06 37 02 FF
CAM_WB
Auto 8x 01 04 35 00 FF Auto
Indoor 8x 01 04 35 01 FF Indoor mode
Outdoor 8x 01 04 35 02 FF Outdoor mode
One Push WB 8x 01 04 35 03 FF One Push WB mode
ATW 8x 01 04 35 04 FF Auto Tracing White Balance
Manual 8x 01 04 35 05 FF Manual mode
Sodium Lamp 8x 01 04 35 0C FF Sodium lamp source fixed mode
One Push Trigger 8x 01 04 10 05 FF
One Push WB Trigger(* Enabled during One Push WB
Mode)
CAM_WB_RGAIN
Reset 8x 01 04 03 00 FF
Manual R gain Setting
(* Enabled during WB Manual mode )
pq = 0x00 To 0x80
Up 8x 01 04 03 02 FF
Down 8x 01 04 03 03 FF
Direct 8x 01 04 43 00 00 0p 0q FF
CAM_WB_BGAIN
Reset 8x 01 04 04 00 FF
Manual B gain Setting
(* Enabled during WB Manual mode )
pq = 0x00 To 0x80
Up 8x 01 04 04 02 FF
Down 8x 01 04 04 03 FF
Direct 8x 01 04 44 00 00 0p 0q FF
