Marshall Amplification CV630-IP Manual

CV630-IP RS-232 Command Set
www.marshall-usa.com9 10
Command Set Command Command Packet Comments
CAM_AE
Full Auto 8x 01 04 39 00 FF Automatic Exposure mode
Manual 8x 01 04 39 03 FF Manual Control mode
Shutter Priority 8x 01 04 39 0A FF Shutter Priority Automatic Exposure mode
Iris Priority 8x 01 04 39 0B FF Iris Priority Automatic Exposure mode
CAM_Flickerless
Off 8x 01 04 3C 00 FF
50Hz 8x 01 04 3C 01 FF
60Hz 8x 01 04 3C 02 FF
CAM_Shutter
Reset 8x 01 04 0A 00 FF
Shutter Setting
(* Enabled during AE Shutter Priority/Manaual Mode)
Up 8x 01 04 0A 02 FF
Down 8x 01 04 0A 03 FF
Direct 8x 01 04 4A 00 00 0p 0q FF
pq: Shutter Position , pq: 00 To 15
(1/1 ~ 1/10000)
CAM_Iris
Reset 8x 01 04 0B 00 FF
Iris Setting
(* Enabled during Iris Priority/Manaual Mode)
Up 8x 01 04 0B 02 FF
Down 8x 01 04 0B 03 FF
Direct 8x 01 04 4B 00 00 0p 0q FF pq: Iris Position , pq: 00 To 0F
Iris Limit (Min.) 8x 01 04 2B 0p FF
p: Iris F number , p: 3 To A (* Disabled during AE
Manual Mode and IrisPri Mode)
Iris Limit (Max.) 8x 01 04 2A 0p FF
p: Iris F number , p: 3 To A (* Disabled during AE
Manual Mode and IrisPri Mode)
Illegal Iris Open
8x 01 04 2F 02 FF
Illegal Open Iris ON/OFF
8x 01 04 2F 03 FF
CAM_Gain
Reset 8x 01 04 0C 00 FF
Gain Setting
(* Enabled during AE Manaual Mode)
Up 8x 01 04 0C 02 FF
Down 8x 01 04 0C 03 FF
Direct 8x 01 04 4C 00 00 0p 0q FF
pq: Gain Position, pq:00 To 0F (* Enabled during AE
Manaual Mode)
(* 0dB ~ +45dB)
Gain Limit 8x 01 04 2C 0p FF
p: Gain Position , p: 3 To F (* Disabled during AE
Manual Mode)
CAM_Bright
Reset 8x 01 04 0D 00 FF
Bright SettingUp 8x 01 04 0D 02 FF
Down 8x 01 04 0D 03 FF
Direct 8x 01 04 4D 00 00 0p 0q FF
pq: Bright Position, pq:0x00~0x0F
(* Enabled during Image Mode = Custom mode )
CAM_ExpComp
On 8x 01 04 3E 02 FF
Exposure Compensation ON/OFF
Off 8x 01 04 3E 03 FF
Reset 8x 01 04 0E 00 FF
Exposure Compensation Amount Setting
(* Enabled during ExpComp On )
Up 8x 01 04 0E 02 FF
Down 8x 01 04 0E 03 FF
Direct 8x 01 04 4E 00 00 0p 0q FF
pq: ExpComp Position , pq: 00 To 0A (* Enabled during
ExpComp On )
Command Set Command Command Packet Comments
CAM_BackLight
On 8x 01 04 33 02 FF
Back Light Compensation ON/OFF
(* Enabled during AE Full Auto Mode)
Off 8x 01 04 33 03 FF
CAM_SpotAE
On 8x 01 04 59 02 FF
Spot Mode ON/OFF
Off 8x 01 04 59 03 FF
Position 8x 01 04 29 0p 0q 0r 0s FF
pq: X - axis, pq: 00 To 06 (* Center position : 3)
rs : Y - axis, rs : 00 To 04 (* Center position : 2)
CAM_Aperture
(Sharpness)
Reset 8x 01 04 02 00 FF
Aperture Control Up 8x 01 04 02 02 FF
Down 8x 01 04 02 03 FF
Direct 8x 01 04 42 00 00 0p 0q FF pq: Aperture Gain, pq: 00 To 0E
CAM_2DNR Set 2DNR Level 8x 01 04 53 0p FF p: NR Level Setting, p: 0 To 3
CAM_3DNR Set 3DNR Level 8x 01 04 54 0p FF
p: NR Level Setting,
p: 0: OFF
1: Low
2: Type
3: Max
CAM_Gamma Gamma setting 8x 01 04 5B 0p FF
p: 0 To 3
(* Enabled during Image Mode = Custom mode )
CAM_LR_Reverse
On 8x 01 04 61 02 FF
Mirror Image ON/OFF
Off 8x 01 04 61 03 FF
CAM_PictureEffect
Off 8x 01 04 63 00 FF
Picture Effect Setting Neg.Art 8x 01 04 63 02 FF
B&W 8x 01 04 63 04 FF
CAM_PictureFlip
On 8x 01 04 66 02 FF
Picture flip ON/OFF
Off 8x 01 04 66 03 FF
CAM_Rotation
(Mirror + Flip)
On 8x 01 04 67 02 FF
Rotation 180 degree ON/OFF
Off 8x 01 04 67 03 FF
CAM_ICR
On 8x 01 04 01 02 FF
ICR ON/OFF
Off 8x 01 04 01 03 FF
CAM_AutoICR
On 8x 01 04 51 02 FF
Auto ICR ON/OFF
Off 8x 01 04 51 03 FF
Threshold 8x 01 04 21 00 00 0p 0q FF pq: Threshold Level, pq: 00 To FF
CAM_Memory
(Preset)
Reset 8x 01 04 3F 00 pp FF
pp: Memory Number (pp: 0x00 To 0x7F)
(* Preset address : 0~127)
Set 8x 01 04 3F 01 pp FF
Recall 8x 01 04 3F 02 pp FF
Reset 8x 01 04 3F 10 pp FF
pp: Memory Number (pp: 0x00 To 0x7F)
(* Preset address : 128~255)
Set 8x 01 04 3F 11 pp FF
Recall 8x 01 04 3F 12 pp FF
CAM_Mute
On 8x 01 04 75 02 FF Mute ON
Off 8x 01 04 75 03 FF Mute OFF
On/Off 8x 01 04 75 10 FF Mute Trigger
