CV630-IP RS-232 Command Set
www.marshall-usa.com15 16
Inquiry Command
Command
Packet
Inquiry Packet Comments
CAM_IllegalIrisOpenInq 8x 09 04 2F FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_GainLimitInq 8x 09 04 2C FF y0 50 0q FF p: Gain Limit,p: 3 To F
CAM_BrightPosInq 8x 09 04 4D FF y0 50 00 00 0p 0q FF pq : Bright Position, pq: 00 To 0xF
CAM_ExpCompModeInq 8x 09 04 3E FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_ExpCompPosInq 8x 09 04 4E FF y0 50 00 00 0p 0q FF pq: ExpComp Position, pq: 00 To 0A
CAM_BackLightModeInq 8x 09 04 33 FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_SpotAEModeInq 8x 09 04 59 FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_SpotAEPosInq 8x 09 04 29 FF y0 50 0p 0q 0r 0s FF
pq : X - axis, pq : 00 To 06
rs : Y - axis, rs : 00 To 04
CAM_ApertureInq 8x 09 04 42 FF y0 50 00 00 0p 0q FF pq: Aperture Gain, pq: 00 To 0E
CAM_2DNRModeInq 8x 09 04 53 FF y0 50 0p FF p: NR Level Setting, p: 0 To 3
CAM_3DNRModeInq 8x 09 04 54 FF y0 50 0p FF
p: NR Level Setting,
p: 0: OFF
1: Low
2: Type
3: Max
CAM_GammaInq 8x 09 04 5B FF y0 50 0p FF Gamma p: 0 To 3
CAM_LR_ReverseModeInq 8x 09 04 61 FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_PictureEffectModeInq 8x 09 04 63 FF
y0 50 00 FF Off
y0 50 02 FF Neg.Art
y0 50 04 FF B&W
CAM_PictureFlipModeInq 8x 09 04 66 FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_RotationModeInq 8x 09 04 67 FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_ICRInq 8x 09 04 01 FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_MuteModeInq 8x 09 04 75 FF
y0 50 02 FF On
y0 50 03 FF Off
CAM Version Inq 8x 09 00 02 FF
y0 50 pp qq rr ss jj jj kk
FF
ppqq: Vender ID(0001)
rrss: Model ID(0513)
jjjj: Rom revision(0104)
kk: Maxinum socket(02)
Inquiry Command
Command
Packet
Inquiry Packet Comments
CAM FW version Inq - Boot
8x 09 00 02 00
00 FF
y0 50 mm nn oo pp qq
rr ss FF
mmnnoo : VBO, ppqqrrss : xxxx
CAM FW version Inq - CM0
8x 09 00 02 00
01 FF
y0 50 mm nn oo pp qq
rr ss FF
mmnnoo : VBP, ppqqrrss : xxxx
CAM FW version Inq -
RTOS
8x 09 00 02 00
02 FF
y0 50 mm nn oo pp qq
rr ss FF
mmnnoo : VBM, ppqqrrss : xxxx
CAM FW version Inq - Linux
8x 09 00 02 00
03 FF
y0 50 mm nn oo pp qq
rr ss FF
mmnnoo : VBR, ppqqrrss : xxxx
CAM FW version Inq - MCU
8x 09 00 02 00
04 FF
y0 50 mm nn oo pp qq
rr ss FF
mmnnoo : VBN, ppqqrrss : xxxx
CAM FW version Inq - IQ
8x 09 00 02 00
05 FF
y0 50 mm nn oo pp qq
rr ss FF
mmnnoo : VBS, ppqqrrss : xxxx
CAM FW version Inq -
CTRL_BD
8x 09 00 02 00
06 FF
y0 50 mm nn oo pp qq
rr ss FF
mmnnoo : VBI, ppqqrrss : xxxx
CAM FW version Inq - CPLD
8x 09 00 02 00
07 FF
y0 50 mm nn oo pp qq
rr FF
mmnnoo : VBK, ppqqrr : xxxx
SYS_MenuModeInq 8x 09 06 06 FF
y0 50 02 FF On
y0 50 03 FF Off
IR_Receive 8x 09 06 08 FF
y0 50 02 FF On
y0 50 03 FF Off
Pan-tiltPosInq 8x 09 06 12 FF
y0 50 0w 0w 0w 0w 0z
0z 0z 0z FF
wwww: Pan Position: 0x0000 to 0x6A40 & 0x95C0 to
0xFFFF (center 0000)
zzzz: Tilt Position: 0x0000 to 0x3840 & 0xED40 to
0xFFFF (center 0000)
CAM Image ModeInq
8x 09 04 3F 04
FF
y0 50 00 FF Default
y0 50 01 FF Custom
Prompt Inq
8x 09 04 07 00
FF
y0 50 02 FF On
y0 50 03 FF Off
CAM SERIAL INQ 8x 09 02 18 FF
y0 50 aa bb cc dd ee ff
gg hh ii FF
aa bb cc dd ee ff gg hh ii : Serial Number (ASCII)
MAC_Address_Read 8x 09 04 78 FF
y0 50 0a 0b 0c 0d 0e 0f
0g 0h 0i 0j 0k 0l FF
MAC Address = ab: cd: ef: gh: ij: kl
Tally Mode Inq
8x 09 7E 01 0A
01 FF
y0 50 0p FF
p: 0: (Red:OFF Green:OFF)
4: (Red:Low light Green:OFF) - Tally Lamp must be
Enabled
5: (Red:Highlight Green:OFF) - Tally Lamp must be
Enable
Tally Lamp Inq
8x 09 7E 01 0A
00 FF
y0 50 0p FF p: 2 Enable 3: Disable
CAM ID INQ 8x 09 7E CE FF
y0 50 aa bb cc dd ee ff
gg hh ii jj kk ll FF
aa bb cc dd ee ff gg hh ii jj kk ll : Camera ID (ASCII)
CAM_ColorGainInq 8x 09 04 49 FF y0 50 00 00 0p 0q FF pq: Color Gain setting , pq: 0x00 To 0x0F
CAM_ColorHueInq 8x 09 04 4F FF y0 50 00 00 0p 0q FF pq: Color Hue setting , pq: 0x00 To 0x0F
IP_DHCP_OnOff_Inq 8x 09 7C 01 FF y0 50 0p FF p: 2: ON, 3: OFF
IP_Address_IPv4_Inq 8x 09 7C 02 FF
y0 50 0p 0q 0r 0s 0t 0u
0v 0x FF
address : pq.rs.tu.vx (HEX)
IP_Netmask_Inq 8x 09 7C 03 FF
y0 50 0p 0q 0r 0s 0t 0u
0v 0x FF
address : pq.rs.tu.vx (HEX)
