CV630-IP RS-232 Command Set
www.marshall-usa.com13 14
Command Set Command Command Packet Comments
CAM_Audio_Encode_
Sample_Rate
Select Audio
Encode Sample
Rate
8x 01 04 6D 0p FF
p: 0: 48KHz (AAC)
1: 44.1KHz (AAC)
2: 16KHz (AAC)
3: 16KHz (G.711)
4: 8KHz (G.711)
CAM_Audio_Delay_
Enable
Set AudioDelay
On/Off for Internet
Streaming
8x 01 04 6F 0p FF p : 2(ON) or 3(OFF)
CAM_Audio_Delay_
Time
Set AudioDelay
Time for Internet
Streaming
8x 01 04 6A 0p 0q 0r FF
pqr : (Hex) delay time, range - 001 ~ 1F4 (1 ~ 500 in
decimal)
14. RS232 Inquiry Command List
Inquiry Command
Command
Packet
Inquiry Packet Comments
CAM_PowerInq 8x 09 04 00 FF
y0 50 02 FF On
y0 50 03 FF Off (Standby)
CAM_SystemStatusInq
8x 09 04 00 01
FF
y0 50 00 FF Ready
y0 50 01 FF Processing
CAM_OpticalZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqrs: Zoom Position , pqrs: 0x0000~0x4000
CAM_
ZoomMemoryModeInq
8x 09 04 47 00
FF
y0 50 02 FF On
y0 50 03 FF Off
CAM_FocusModeInq 8x 09 04 38 FF
y0 50 02 FF Auto Focus
y0 50 03 FF Manual Focus
CAM_FocusPosInq 8x 09 04 48 FF y0 50 0p 0q 0r 0s FF pqrs: Focus Position, pqrs: 0x000 to 0x47A
CAM_CurveModeInq
8x 09 04 38 03
FF
y0 50 02 FF Curve tracking
y0 50 03 FF Zoom tracking
AF SensitivityInq 8x 09 04 58 FF
y0 50 01 FF High
y0 50 02 FF Middle
y0 50 03 FF Low
AF FrameInq 8x 09 04 5C FF
y0 50 01 FF Auto
y0 50 02 FF Full Frame
y0 50 03 FF Center
Inquiry Command
Command
Packet
Inquiry Packet Comments
Resolution SetttingInq 8x 09 06 23 FF y0 50 0p 0q FF
pq:
0x05:QFHD 4K(3840 x 2160) - 29.97p
0x06:QFHD 4K(3840 x 2160) - 25p
0x08:FHD 1080P(1920 x 1080) - 59.94p
0x09:FHD 1080P(1920 x 1080) - 50p
0x0B:FHD 1080P(1920 x 1080) - 29.97p
0x0C:FHD 1080P(1920 x 1080) - 25p
0x0E:HD 720P(1280 x 720) - 59.94p
0x0F:HD 720P(1280 x 720) - 50p
0x11:HD 720P(1280 x 720) - 29.97p
0x12:HD 720P(1280 x 720) - 25p
CAM_HdmiOutputRangeInq 8x 09 06 37 FF
y0 50 01 FF 16~235
y0 50 02 FF 1~254
CAM_WBModeInq 8x 09 04 35 FF
y0 50 00 FF Auto
y0 50 01 FF In Door
y0 50 02 FF Out Door
y0 50 03 FF One Push WB
y0 50 04 FF ATW
y0 50 05 FF Manual
y0 50 0C FF Sodium Lamp
CAM_RGainInq 8x 09 04 43 FF y0 50 00 00 0p 0q FF pq : R Gain, pq: 00 To 80
CAM_BGainInq 8x 09 04 44 FF y0 50 00 00 0p 0q FF pq : B Gain, pq: 00 To 80
CAM_AEModeInq 8x 09 04 39 FF
y0 50 00 FF Full Auto
y0 50 03 FF Manual
y0 50 0A FF Shutter Priority
y0 50 0B FF Iris Priority
CAM_FlickerlessInq 8x 09 04 3C FF
y0 50 00 FF Off
y0 50 01 FF 50Hz
y0 50 02 FF 60Hz
CAM_ShutterPosInq 8x 09 04 4A FF y0 50 00 00 0p 0q FF pq: Shutter Position, pq: 00 To 15
CAM_IrisPosInq 8x 09 04 4B FF y0 50 00 00 0p 0q FF pq: Iris Position, pq: 00 To 0F
CAM_GainPosInq 8x 09 04 4C FF y0 50 00 00 0p 0q FF pq: Gain Position, pq: 00 To 0F
CAM_IrisLimitInq (Min.) 8x 09 04 2B FF y0 50 0q FF p: IRIS Limit,p: 3 To A
CAM_IrisLimitInq (Max.) 8x 09 04 2A FF y0 50 0q FF p: IRIS Limit,p: 3 To A
