Marshall Amplification ORIGIN 50 - Front Panel Functions; Power and Output Controls; Tone Shaping and Equalisation

1. POWER SWITCH
Turns your amplier on and off.
2. OUTPUT LEVEL
Adjusts the output power level. At high
power the output will be the maximum
available power level. At mid power the
output of the amplier is set for quieter
performance use and recording (ORI20:
approx. 3W / ORI50: approx. 10W). At
low power the output will be reduced for
home practice (ORI20: approx. 0.5W /
ORI50: approx. 0.5).
Note: reducing the power output allows
you to drive the power stage harder at
low volumes. This provides the ability to
benet from the rich tonal qualities that a
valve power amp can create without the
need to operate at loud volume levels.
3. POWER LIGHT
When the unit is switched on this light
will illuminate.
4. PRESENCE
Adjusts the response of the power
amplier increasing the higher
frequencies of your sound.
5. MASTER VOLUME
Adjusts output volume. At higher settings,
the power amplier can be overdriven,
giving a classic overdrive sound.
EQ Settings: your Origin amplier has
4 equalisation controls (presence, treble,
middle and bass) plus an amplier channel
voice control (tilt). All these controls allow
you to adjust the frequency and voicing.
Each control is highly effective and
interactive.
6. TREBLE
Controls the higher frequency of
your sound.
7. MIDDLE
Controls the middle frequency of
your sound.
8. BASS
Controls the lower frequency of
your sound.
ORIGIN HEAD (COMBO SHOWN ON NEXT PAGE)
1
4
32 5
6
7 8 9 10 11
ENGLISH
3.0
FRONT PANEL FUNCTIONS
THE INFORMATION SHOWN APPLY TO BOTH 20 AND 50, HEAD AND COMBO FORMATS.
