Marshalltown Bullet MARKSMAN - Page 10

10 of 56
104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 • Fax 800-477-6341 / 641-753-6341 www.MARSHALLTOWN.com WS2522
REF # DESCRIPTION EDI PART# QTY
1 22⁄ x 2 SHEAR RAIL , 0.95" C2C WC1005 CON-RAL-W022 2
2 ⁄ " DIAMETER CAM LOCK PIN R7154 CON-CML-D900 1
3 009 UPPER HANDLE R7204 CON-HAN-U009 1
4 SHARPSHOOTER & MARKSMAN PIN WU915 COT-PIN-0400 2
5 ⁄ X 1⁄" FLAT HEAD AL RIVET WR1553 FAS-RVT-2513 2
6 ⁄-20 x 2" BHSCS ZINC PLT WR1584 FAS-SCW-5420 4
7 M6-1 x 12 BHSCS ZINC PLT WR1585 FAS-SCW-5612 14
8 BOLT, M10 x 80 HEX, 10.9, ZINC PLT WR1510 FAS-BLT-EZ80 2
9 M8-1⁄ x 40 BHSCS ZINC PLT WR1589 FAS-SCW-5840 2
10 HANDLE GRIP, (1 x 1 x 5 x ⁄") WK232 GEN-HAN-0868 1
11 RIVETED SHEAR FENCE 19⁄" R7178 CON-FNC-1000 1
12 M6-1 x 16 FHPMS ZP WR1604 FAS-SCW-8569 4
13 #10 x 1 FHPSMS WR1556 FAS-SCW-0010 3
14 M6-1 x 2  BH TORX MS ZINC PLT WR1598 FAS-SCW-7625 4
15 PIN, TENSION, M10 x 30 WR1548 FAS-PIN-EZ02 2
16 FOOT CAP, ⁄" BLACK VINYL, FCR-12 WL793 GEN-CAP-5039 2
17 EZ END CAP, BLACK, FITS SQ TUBE ID OF 0.584 - 0.68" WL790 GEN-CAP-1075 1
18 SPRING, COMPRESSION, 0.989 x 4", x 0.105, 14 COIL WR1635 GEN-SPR-4075 2
19 BUTTON SPRING, HAIRPIN, ⁄  WR1630 GEN-SPR-0847 1
20 MARKSMAN " CAMSHAFT R7126 CON-CAM-1113 1
21 MARKSMAN " HEAD R7215 CON-HED-1113 1
22 MARKSMAN " BASE R7088 CON-BSE-1113 1
23 MARKSMAN " TABLE R7332 PLA-TBL-1113 1
24 M ARKSMAN " TAIL R7309 PLA-TAL-1113 1
25 ES00-EX13 BLADE STOP R7120 CON-BST-EX13 1
26 ES00-EX13 ANVIL R7023 CON-ANV-EX13 1
27 EZ-13 FLR BLADE WX2582 RAW-BDE-113B 1
28 M6-1.0 x 30 SHCS ZP WR1577 FAS-SCW-2630 1
29 .40 S&W SPENT CASING WX2532 GEN-BUL-LET4 1
30
SHARPSHOOTER PRO AND MARKSMAN LOWER
HANDLE
R7198 CON-HAN-L100 1
31 M- X , SHCS, ZINC PLT WR1581 FAS-SCW-5021 2
32
BEARING ASSEMBLY, MARKSMAN
SHARPSHOOTER PRO
7527 SUB-BNG-0150 2
PARTS BREAKDOWN
