Marti Electronics SRPT-40A - Factory Test Report; Test Report Fields and Settings

8/7/2003
37
SRPT-30/40A TRANSMITTER
FACTORY TEST REPORT
Customer: ________________________ Address: _______________________________________
Serial No.: __________ _______________________________________
____Set internal switching power supply = 13.0 Volts
____Program synthesizer
____Frequency measurement, adjust, and changing
____Forward power calibration and metering
____Reverse power calibration and metering
____Current metering calibration
____Verify B+ metering
____Audio board limiter set
____Audio compressor meter set to 0 VU
____Signal to noise within specifications
____Frequency response within specifications
____Distortion within specifications
____Set deviation to _____kHz corresponding to 100% modulation
____Set encode frequency to 27 Hz
____Set encode frequency deviation to 600 Hz
____Test 12-15 VDC external supply and low-voltage dropout
____Calibrate internal regulator and test 15-30 VDC external supply
____Test accessory functions
24-Hour Burn-in: Start: Date_________ Time_________
Stop: Date_________ Time_________
____Fine tune frequency adjust at ________MHz
____Max power adjust to ______Watts
Customer Specific Settings (if different from standard):
Encode deviation________ Audio response________ Max power________
Channel settings (SRPT-40A only - upon request):
CH0:________MHz CH1:________MHz CH2:________MHz CH3:________MHz
CH4:________MHz CH5:________MHz CH6:________MHz CH7:________MHz
CH8:________MHz CH9:________MHz
____Frequency change disabled (SRPT-40A only)____Channel change disabled (SRPT-40A only)
DATE:_____________ SIGNATURE:__________________________________
