44. Adjust the MAX PWR pot (R74) on the SYNHESIZER to the desired maximum output power, but again, do not
exceed the Maximum RF Output Power as specified in ORDERING INFORMATION corresponding to your
model.
45. Replace the cover on the SYNTHESIZER.
46. On the FRONT PANEL CONTROL & METER board, adjust S1 dip-switches with switch 1 and 2 “ON”, and 3 and
4 “OFF”. This places the SRPT-40A back into normal operation.
TABLE 2 – Forward and Reverse Power Calibration
MODEL CAL
FREQUENCY
(MHz)
FWD CAL PWR
LEVEL (W)
REV CAL PWR
LEVEL (W)
SRPT40A-150 175.0000 64.0 32.0
SRPT30-150 175.0000 38.4 19.2
SRPT40A-230 235.0000 32.0 12.8
SRPT30-230 235.0000 32.0 12.8
SRPT40A-250 250.0000 32.0 12.8
SRPT30-250 250.0000 32.0 12.8
SRPT40A-330 330.0000 32.0 12.8
SRPT30-330 330.0000 32.0 12.8
SRPT40A-450 450.0000 56.0 25.6
SRPT30-450 450.0000 32.0 12.8
SRPT40A-950 950.0000 22.4 9.6
SRPT30-950 950.0000 22.4 9.6
