P/N 705-ST40A-xx
(see legend below for xx(x) and yy)
SRPT40A/xxx
1/10/03
Control Knob, #ME450-2023 510-215 4
Fan, NMB 2410ML04WB40-P00 or ADDA #AD0612HS-A70GL 510-231 1
Flexible Grommet, Tyton FP/A (82' per roll) 510-246 1
Shrink-Tubing, 1/8" B2 Black 510-259 0.1
Spacer, #6 x 1/4 round Keystone 1457A 513-019 2
Spacer, 4-40 x 1/2 hex threaded Keystone 1450C 513-026 2
Spacer, 4-40 x 1/2 hex threaded insulated Keystone 1902C 513-040 4
Switch, slide DPDT Switchcraft 46206LR 530-001 1
Switch, toggle SPDT C&K 7101MYZQ or Apem #5636AB16 530-008 1
Switch, Pushbutton,SPST, Momentary, Green, Mouser#103-1209 530-085 1
Switch,Pushwheel,BCD 10 Position Mouser #106-9905 530-087 7
Switch End Cap, Right Side Mouser#106-9901 530-088 1
Switch End Cap, Left Side Mouser #106-9902 530-089 1
Switch, Rocker, Miniature,DPDT, Red Mouser #629-GRS402210 530-090 1
Connector, Tini-Jax Switchcraft 41 550-083 1
Connector Shell XLR Receptacle 550-155-2 4
Connector pins, Molex 16-02-0086 550-205 4
Connector, 4 Pin Single Row Housing Molex #M0L50-57-9004 550-229 2
Wire, UL1061 22/7 OTC Black 580-040 1
Wire, UL1061 22/7 OTC White/Violet 580-058 0
Wire, UL1061 22/7 OTC Yellow/Violet 580-061 0
Cable Assembly w/2 conn. KSM-2189-05" 586-115 1
Ribbon Cable 6" Digi Key #M3AAA1606R-ND 586-134 1
Cable Assembly, AC Connector to Fuseholder 586-194 1
Cable Assembly, AC Connector to Ground 586-195 1
CABLE ASSEMBLY, SRPT-30/40A MN HRNS(SBCM) 586-211 1
Cover,Two Stage Power Amplifier 700-226-61 1
Front Panel, SRPT-40A 700-250-42 1
SRPT-40A Audio Board 800-166A40A 1
RPT-30/SRPT-40 Pre-Amp Mixer(SBCM) 800-251A 1
TRANSMITTER SYNTHESIZER ASSY xxx Band 800-375ATxxx 1
RPU Transmitter I/O Board Assy (SBCM) 800-379AR 1
Power Supply, Switching 15V, 10 Amp 800-383A 1
Uses one of the following Front Panel Control & Meter Boards:
SRPT-40A FRONT PANEL CONTROL & METER 800-385A 1
OR
SRPT-40A FRONT PANEL CONTROL & METER 800-378A 1
Uses one of the following PA assemblies:
PA ASSY, xxx MHZ, yyW 800-388Axxx-yy 1
OR
PA ASSY, xxx MHZ, yyW 800-373Axxx-yy 1
14.5 VOLT STEP-UP REGULATOR 800-392A 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
