P/N 586-211
(see legend below for xx(x) and yy)
Cable Assembly,
SRPT-30/40A Main Harness
10/30/02
SYMBOL DESCRIPTION PART NUMBER QTY
LUG,QUICK DISCONNECT #18-22 410-1421 3
LUG,TERM #6 SPADE #16-22 410-1489 7
HSNG,MOD IV 4 POS 87499-7 AMP 417-0138 1
CONTACT,CRIMP,MOD-IV 87809-1 417-8766 28
Solder Lug, #6 Concord 707-1406 512-009 2
Terminal,NICHIFU TMDN #125-250-03FA TERMINAL 512-020 5
Connector, 6 pin Molex housing 09-50-8060 550-135 2
Connector, Crimp Terminal Pin Molex 08-52-0112 550-327 39
Wire, UL1061 22/7 OTC Black 580-040 5
Wire, UL1061 22/7 OTC White 580-042 1
Wire, UL1061 22/7 OTC Red 580-043 4
Wire, UL1061 22/7 OTC Yellow 580-044 2
Wire, UL1061 22/7 OTC Green 580-046 1
Wire, UL1061 22/7 OS-1 Orange 580-047 1
Wire, UL1061 22/7 OTC Violet 580-048 1
Wire, UL1061 22/7 OTC Slate 580-049 1
Wire, UL1061 22/7 OS-1 White/Red 580-050 2
Wire, UL1061 22/7 OTC White/Blue 580-051 2
Wire, UL1061 22/7 OTC White/Orange 580-052 1
Wire, UL1061 22/7 OTC White/Brown 580-055 2
Wire, UL1061 22/7 OTC White/Slate 580-056 3
Wire, UL1061 22/7 OTC White/Violet 580-058 2
Wire, UL1061 22/7 OTC Yellow/Blue 580-059 2
Wire, UL1429 22/7 OS-1 Yellow/Green 580-060 2
Wire, UL1061 22/7 OTC Yellow/Brown w/ overall tin coatin
g
580-065 1
Shielded Wire, 16-C-22-SPJ White/Orange 1 cond 22/19x34
580-089 2
Shielded Wire, 16-C-22-SPJ White/Yellow 1 Cond.22/19x34
p
580-090 1
Shielded Wire, 16-C-22-SPJ White/Green 1 Cond.22/19x34
p
580-091 2
Shielded Wire, 16-C-22-SPJ White/Blue 1 Cond.22/19x34 p
v
580-092 1
Wire, Stranded UL1015-20/10 Black Tinned Copper 580-130 6
Wire, UL1061-18/16 #18 Red #M370-2 580-133 12
Wire, UL1061-18/16 #18 Blue 580-136 1
WIRE,AWG22,19/34 WHT 601-2209 1
J1 Connector, 10 pin Molex housing 09-50-8100 550-122 1
J1,J2 Connector, 8 pin Molex housing 09-50-8080 550-137 2
J2,J3 HOUSING, 16 PIN, DOUBLE ROW, AMP 1-87456-2 417-0602 2
J3 HOUSING,SKT,6PIN,AMP MOD IV 417-0601 1
J6 Connector, 8 pin Molex housing 09-50-8080 550-137 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
