P/N 800-388A
or 800-373A
(see legend below for xx(x) and yy)
TWO-STAGE RF PA
BOARD ASSEMBLY
1/10/03
SYMBOL DESCRIPTION PART NUMBER QTY
TAPE,KAPTON 1/4 700-0119 0
RF Shielding Fence For Power Amplifier(Interior) 700-226-59 1
Leader Tech Fence # 47-CBSU-2.75 X 5.75 X .4 NO COVER 700-268 1
PC BOARD, TWO-STAGE RF PA 800-388B 1
C1-C6 Cap, Monolithic chip 10000pF 10% XR7 Kemet C1206C103J5RACTR 270-103 6
C7 Cap., SMT, 1206, 4700 pf, COG, 100V, Kemet C1206C472J5GACTU 270-472 1
C8 Cap., Tantalum, SMT, Size B, 10uF, 16V,Kemet T491B106K016AS 298-106 1
C9 Cap., SMT, 1206, 4700 pf, COG, 100V, Kemet C1206C472J5GACTU 270-472 1
C10 Cap., Tantalum, SMT, Size B, 10uF, 16V,Kemet T491B106K016AS 298-106 1
C11 Cap., SMT, 1206, 4700 pf, COG, 100V, Kemet C1206C472J5GACTU 270-472 1
C12 Cap., Tantalum, SMT, Size B, 10uF, 16V,Kemet T491B106K016AS 298-106 1
C15 Cap., SMT, 1206, 4700 pf, COG, 100V, Kemet C1206C472J5GACTU 270-472 1
C16 Cap.,Tantalum,SMT,Size C, 33uF,16V,Sprauge T491C336K016AS 298-336 1
C17,C18 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 2
C19 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C20 Cap.,Tantalum,SMT,Size C, 33uF,16V,Sprauge T491C336K016AS 298-336 1
C21,C22 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 2
C23 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C24 Capacitor, Monolithic Chip 100000pF 1% C1206C104J5RAC Kemet 270-104 1
C25-C28 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 4
C29 Cap.,Tantalum,SMT,Size C, 33uF,16V,Sprauge T491C336K016AS 298-336 1
C30 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 1
C31 Cap.,Tantalum,SMT, Size D, 100uF, 16V,Kemet T491X107K016AS 298-107 1
C32-C34 Cap,monolithic,1000pf 50v 5%KemetC1206C102J5GACTR marked 270-102 3
C40 Cap SMT 1mF 16V Tantalum Kemet T491A105M016AS 298-105 1
D3,D4 Diode, Motorola MMBD101L chip 410-305 2
D5 Diode, Zener, SMT, 2.5V, Motorola MMSZ5222BT1 415-222 1
D6 Diode, Zener, SMT, 13V, Vishay BZX84C13TR 415-840 1
D7 Diode, SMT, Zener, 4.7V, Motorola BZX84C4V7LT1 418-447 1
L1 Inductor, SMT, Power, 0.68, Coilcraft DO3316P-681HC 350-196 1
L2,L3 Inductor, SMT, 1008, 330nH, Coilcraft 1008CS-331XKBC 350-191 2
L4-L6 Inductor, SMT, Power, 1uH, Coilcraft DT1608C-102 350-197 3
L7 Inductor, SMT, 1008, 330nH, Coilcraft 1008CS-331XKBC 350-191 1
P1 Connector, 8 pin Molex header (cut from 550-162) 550-138 1
P2 Connector, S.FL2-R-SMT surface mount Hirose 550-193 1
P3 Connector,6-Pin Header 550-324 1
Q1,Q2 Transistor, SMT, PNP, Motorola MMBT2907ALT1 420-907 2
Q3 Transistor, SMT, General Purpose,NPN, Motorola MMBT3904LT1 439-041 1
Q4 Transistor, SMT, NPN, Motorola MMJT9410 429-410 1
Q5 Transistor, SMT, General Purpose,NPN, Motorola MMBT3904LT1 439-041 1
R2 Resistor, SMT, 1206, 274 ohm, Dale CRCW1206-274 185-274 1
R3 Resistor,SMT, 3Watt. 0.05 ohms, Dale WSR-3-.05-1% 184-005 1
R4 Resistor, SMT, 1206, 4.75K, Dale CRCW1206-4.75K 185-4.75K 1
R5 Potentiometer, 5K ohms, SMT, Bourns 3224W-1-502E 108-502 1
R6 Resistor, SMT, size 1206, 392 ohms, Dale CRCW1206-392 185-392 1
R7 Resistor, Dale CRCW1206-100 1/8 W 100 ohm chip 185-101 1
R8-R10 Resistor, SMT, 3 Watt, 0.1 ohm 1%, Dale WSR-3-.1-1% 184-001 3
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
1
