Marti Electronics SRPT-40A - Page 89

P/N 959-0321
(see legend below for xx(x) and yy)
ASSY., THERMOCOUPLE
10/30/02
SYMBOL DESCRIPTION PART NUMBER QTY
Thermistor, Fenwal 142-102-FAG-RB1 1000 OHM @ 25C 10% 120-002 1
Terminal, vinyl insulated C10 #10 stud #10-12 wire 512-002 1
Hysol Epoxi-Patch Kit 11C Black 900-019 0
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
1
