P/N 800-166A40ATSL
(see legend below for xx(x) and yy)
SRPT30/40A TSL Audio Board
5/2/03
SYMBOL DESCRIPTION PART NUMBER QTY
RIV,CLOSED-END .125 X .316L 421-1113 2
Generic RPU Audio Board Assembly (SBCM) 800-166CM 1
C23 Capacitor, .022 mfd 2.5% 100v polypro Seacor 215-223 1
R43 Resistor, 1k ohm 1/4 watt 1% metal film Mepco SFR55 1K 1%TR 145-102 1
R46 Resistor, 8.25k ohm 1/4 watt 1% metal film 145-822 1
R48 RES,1 OHM,1/4W,5% 100-1013 1
R49 Resistor, 2.21 meg ohm 1/4 watt 1% metal film (2.21 Meg 1%) 145-225 1
xx(x) = 15(0), 23(0), 25(0), 33(0),
45(0), or 95(0) depending on
model frequency band
yy = 20, 30, 50, or 60
depending on
model MAX power
1
