8. Horizontal aiming
Horizontal angles should be set so that the loudspeaker’s main horizontal coverage is directed
towards the main listening area. Avoid excessive reflections from nearby side walls.
The following example shows AQ Series loudspeakers with 80 - 90
° horizontal dispersion (all
except AQ5) toed in 40 - 45° from the side walls
AQ6, AQ8, AQ10, AQ12, AQ15 aiming
AQ5 placement
For the cleanest coverage, AQ5 dual-driver loudspeakers are best kept away from tight corners
that open to less than
100°.
The AQ5 is not recommended for use in tight corners
All material © 2007. Martin Audio Ltd. Subject to change without notice.
