Main features
Very wide 120° x 60° dispersion
120Hz – 20kHz
75W AES (300W peak)
4 ohms or 16 ohms (low profile switch on rear)
Dual 5.25” (130mm) ICT™
The ultra-compact Martin Audio AQ5 is equipped with two 5.25” (130mm) ICT™ - Inductively
Coupled Transducer - drivers optimally splayed for smooth, very wide coverage. The AQ5’s HF
diaphragms are driven via inductive coupling, avoiding the tweeter burn-out commonly associated
with miniature loudspeakers. ICT™ technology also obviates the need for a crossover as the
inductive coupling provides a complementary transfer function for the tweeter.
AQ6 (standard)
AQ6 (16 ohm version)
AQ6TX30 (100V or 70V line version)
Main features
Wide 90° conical dispersion
80Hz – 20kHz
100W AES (400W peak)
Two-way 8 ohm passive (16 ohm to special order)
6.5” (165mm) direct radiating LF cone + 1” (25mm) horn-loaded dome tweeter
The Martin Audio AQ6 is a two-way passive loudspeaker designed to fulfil the requirement for
dynamic performance from a very small, architecturally friendly, vented enclosure. It features a 6.5”
direct radiating, long-throw bass unit and a 1” doped fabric dome driver coupled to a constant
directivity square coverage HF horn.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
