Martin Audio AQ Series User Manual

Main features
Wide 90° x 50° dispersion
Rotatable HF horn
65Hz – 20kHz
300W AES (1200W peak)
Two-way 8 ohm passive
10” (250mm) direct radiating LF cone + 1” (25mm) exit horn-loaded HF compression driver
The Martin Audio AQ10 is a two-way passive loudspeaker designed to provide high sound
pressure levels from a compact, architecturally friendly, heavily braced, vented enclosure. It
features a 10” (250mm) long-throw, direct radiating bass driver with a 2.5” (63mm) voice coil and a
1.4” (35mm) diaphragm, 1” (25mm) exit compression driver coupled to a true constant directivity
HF horn.
AQ12 (standard)
AQ12TX150 (100V or 70V line version)
Main features
Wide 80° x 50° dispersion
Rotatable HF horn
62Hz – 18kHz
300W AES (1200W peak)
Two-way 8 ohm passive
12” (300mm) direct radiating LF cone + 1” (25mm) exit horn-loaded HF compression driver
The Martin Audio AQ12 is a two-way passive loudspeaker designed to provide high sound
pressure levels from an architecturally friendly, heavily braced, vented enclosure. It features a 12”
(300mm) long-throw, direct radiating bass driver with a 2.5” (63mm) voice coil and a 1.7” (43mm)
diaphragm, 1” (25mm) exit compression driver coupled to a true constant directivity HF horn.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
