Copyright © 2019 Martin Audio Ltd. 8
BLACKLINEX POWERED USER GUIDE V1.0
BLACKLINEX POWERED USER GUIDE
Series Overview
XP12
The XP12 fulfils the requirement for a compact system that can deliver high SPL — either as a stand-alone system or supplemented by
the XP118 subwoofer. Featuring a 12” (300mm) LF driver unit and a 1” (25mm) exit compression driver on a rotatable horn, its 80° x 50°
dispersion pattern is ideal for short to medium throw applications. The LF driver has a 2.5” (65mm) voice coil and a high BL motor, while
the HF compression driver utilises a 1.75” (44mm) polyimide diaphragm for extended high frequency response.
The XP12’s enclosure is constructed from birch/poplar plywood and coated in black textured paint. For easy removal, its steel grille is a
spring-fit into the sides of the enclosure. The XP12 is fitted with M8 inserts for a wall bracket and eyebolt suspension, plus a pole-mount
socket with a removable bung that maintains clean lines when the XP12 is used in install applications
XP15
The XP15 is a high powered two-way system designed for professional portable applications and installations that demand the ultimate in
sonic performance from a single enclosure. With an accurately-defined 80° x 50° coverage pattern, it combines high output capability with
exceptional sonic performance and impact.
The XP15 features a 15” (380mm)/3” (75mm) voice coil LF drive unit, and a 1” (25mm) exit HF compression driver with a 1.75” (44mm)
polyimide diaphragm for extended high frequency response.
Its protective steel grille is a spring-fit into the sides of the enclosure for easy access to rotate the HF horn. The symmetrical, multi-angle
enclosure is manufactured from birch/poplar ply and coated in textured black paint. The XP15 is fitted with M8 inserts for a wall bracket
and eyebolt suspension, plus a pole-mount socket.
