LE700A
TYPE Two way active monitor
BANDWIDTH 60Hz-18kHz ±3dB
DRIVERS 15” (385mm) dia. 4” (100mm) voice coil
1.4” (35mm) exit compression driver
RATED POWER LF: 400W AES, 1600W peak
HF: 75W AES, 300W peak
RECOMMENDED AMPLIFIER 550-800W into 4 ohms
SENSITIVITY LF: 98dB / HF: 106dB
MAXIMUM SPL LF: 123dB continuous, 129dB peak
HF: 125dB continuous, 131 dB peak
IMPEDANCE LF: 8 ohms nominal
HF: 16 ohms nominal
CROSSOVER 1000Hz
DISPERSION 50-100 degs horizontal
(differential dispersion),
70 degs vertical
ENCLOSURE 80 litres
CONNECTORS 2 x Speakon
DIMENSIONS (W) 710mm x (H) 470mm x(D) 554mm
(W) 27.9ins x (H) 18.5ins x (D) 21.8ins
WEIGHT 44kg (97lbs)
SHIPPING DIMENSIONS (W) 820mm x (H) 520mm x (D) 570mm
(W) 32.3ins x (H) 20.5ins x (D) 22.4ins
SHIPPING WEIGHT 46kg (101.4lbs)
NO
TES (LE Series)
Sensitivity measured in half-space conditions at 1 metre with 1 watt input,
using band limited pink noise.
SPL measured at 1 metre using band limited pink noise.
Finish: Black textured paint.
Protective grilles: Perforated steel black with 48% free air flow.
Cabinet construction: Birch ply.
Due to our policy of continuous improvement all specifications are subject
to change without notice.
Martin Audio – LE SERIES
ENGLISH
10
