LE400C
TYPE Active/passive monitor
BANDWIDTH 50Hz-18kHz ±3dB
DRIVERS 15” (385mm) dia. 3” (75mm) voice coil
1” (25mm) exit compression driver
RATED POWER LF/FR: 300W AES, 1200W peak.
HF: 60W AES, 240W peak
RECOMMENDED AMPLIFIER 500-700W into 4 ohms
SENSITIVITY LF/FR: 98dB / HF: 106dB
MAXIMUM SPL LF/FR: 121dB continuous,127dB peak
HF: 123dB continuous 129dB peak
IMPEDANCE LF/FR: 8 ohms nominal
HF: 8 ohms nominal
CROSSOVER 1200Hz
DISPERSION 40 degs horizontal, 70 degs vertical
ENCLOSURE 70 litres
CONNECTORS 2 x Speakon
DIMENSIONS (W) 660mm x (H) 470mm x (D) 554mm
(W) 26.0ins x (H) 18.5ins x (D) 21.8ins
WEIGHT 32.5kg (72lbs)
SHIPPING DIMENSIONS (W) 760mm x (H) 500mm x (D) 594mm
(W) 29.9ins x (H) 19.7ins x (D) 23.8ins
SHIPPING WEIGHT 38kg (83.8lbs)
Martin Audio – LE SERIES
