9 TECHNICAL SPECIFICATIONS
LE350A
TYPE Passive monitor
BANDWIDTH 70Hz-18kHz ±3dB
DRIVERS 12” (305mm) dia., 3” (75mm) voice coil
1” (25mm) exit compression driver
RATED POWER 300W AES, 1200W peak.
RECOMMENDED AMPLIFIER 500-700W into 4 ohms
SENSITIVITY 97dB
MAXIMUM SPL 119dB continuous,
125dB peak
IMPEDANCE 8 ohms nominal
CROSSOVER 1500Hz
DISPERSION 50-100 degs horizontal
(differential dispersion),
70 degs vertical
ENCLOSURE 36 litres
CONNECTORS 2 x Speakon
DIMENSIONS (W) 607mm x (H) 318mm x(D) 428mm
(W) 23.9ins x (H) 12.5ins x (H) 16.9ins
WEIGHT 23.2kg (51lbs)
SHIPPING DIMENSIONS (W) 710mm x (H) 420mm x (D) 510mm
(W) 28ins x (H) 16.5ins x (D) 20.1ins
SHIPPING WEIGHT 16kg (35.3lbs)
Martin Audio – LE SERIES
ENGLISH
7
